Mondraker - SUPERFOXY Bike - Silver/Blue (SUPER ENDURO)

Name: Mondraker - SUPERFOXY Bike - Silver/Blue (SUPER ENDURO)
Brand: Mondraker
SKU: MOND-B-Sfoxy-Silver23-S
Price: 5419.0 USD
Availability: OutOfStock

SKU: MOND-B-Sfoxy-Silver23-S

$5,419.00 USD ~~$5,499.00~~

Shipping calculated at checkout.

Size

S M L XL

Color: Silver-Blue

Mondraker - SUPERFOXY Bike - Silver/Blue (SUPER ENDURO)

Product variants

NOTE:
Pre-orders only. Subject approval to availability and delivery times.
Please call us for availability and all other information at 805-850-3200.

DESCRIPTION

Sizes: S: 380mm / M: 420mm / L: 470mm / XL: 510mm
Colors: Gloss Racing Silver / Marlin Blue

Experience the Superfoxy difference in enduro, trail, uphill, and downhill! This top-end mountain bike boasts more travel and a sleeky frame for the gnarliest, hardcore trails. The 2023 model the Superfoxy gets a tuned Fox 38 fork and a Fox Float X shock to make the bike shine in any situation.

Mondraker’s unique zero suspension system helps with stability and control by absorbing the strongest vibrations and keeping your wheels planted on the ground even on the bumpiest of the trails. This superior suspension design offers zero power loss for pedaling stability, zero pedal kickback for minimum chain growth throughout travel, zero brake jack for isolated braking & suspension forces, and zero bumps for absorbing even the slightest bumps for extreme rear wheel stability.

Heavy enduro riders will love the safety and confidence offered by Mondraker’s proprietary forward geometry design. Forward geometry also helps with improved handling, overall control, uphill precision, and stability in tough terrains.

The durable stealth alloy frame helps with resistance and mobility for better speed and performance. Stealth Alloy technology uses smartly designed tubes catering to specific functions with the goal of achieving the lowest weight.

Superfoxy 2021 features telescopic Seatpost internal routing and enduro sealed bearings to withstand the rigors of demanding trails. Superfoxy is loaded with features such as super-boost rear axle and dedicated 1X drivetrain for better traction and momentum.

Superfoxy goes above and beyond with more exclusive features like BSA bottom bracket for improved brake efficiency and noise control. One-piece monoblock upper link offers better lateral and torsional stiffness to reduce lateral stress on the shock action.

Superfoxy sports high-performance rear derailleurs and wide 29” tubeless-ready tires, for ultimate precision and grip through uneven and rough trails. Extreme riders can conquer rigorous trails in the comfort of consistent and unstoppable braking power from durable, all-terrain compatible, MTB brakes.

SPECS

COMPONENTS / TECHNICAL SPECIFICATIONS

FRAME	SuperFoxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 160mm travel,Forward Geometry, one piece Monoblock upper link, SuperBoost 12x157mm rear axle, tapered headtube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing,Max. capacity sealed bearings, ISCG 05
SIZES	S: 380mm / M: 420mm / L: 470mm / XL: 510mm
REAR SHOCK	Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings
SHOCK SETTINGS	Medium compression, medium rebound, air volume spacer 0.2
FORK	Fox 38 29 Float GRIP RHYTHM, 170mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
HEADSET	Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45°x45°,bottom 51.9x40x8x45°x45°
STEM	Onoff Sulfur FG 30mm 0°, 6061 forged alloy, 31.8mm barbore
HANDLEBAR	Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9° backsweep, 5° upsweep,31.8mm barbore
GRIPS	Onoff Twin, 1lock-on, 135mm
SEATPOST	Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L size:425x150mm, XL size: 465x170mm
SADDLE	SDG BEL-AIR 3.0, LPU foam, steel rails
FRONT BRAKE	Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
REAR BRAKE	Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
BRAKE LEVER	Sram DB8, tool-free reach adjust
RIMS	e*thirteen LG1 Enduro, IW30 Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes
SPOKES	e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
FRONT HUB	e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
REAR HUB	*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, Shimano freehub
FRONT TIRE	Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
REAR TIRE	Maxxis Dissector 29x2.4WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
CRANKSET	Truvativ Descendant 7K Eagle, SuperBoost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
RINGS	32T, CNC-machined alloy, X-SYNC 2
BOTTOM BRACKET	Sram DUB BSA, sealed bearings, 73mm
PEDALS	-
CHAIN	Sram SX Eagle, 12s, Powerlock
FRONT DERAILLEUR	-
REAR DERAILLEUR	Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
SHIFT LEVERS	Sram Trigger SX Eagle, 12s, X-Actuation 1:1
CASSETTE	Sram PG-1210, 11-50T, 12s
MOTOR	-
BATTERY	-
DISPLAY	-
DERAILLEUR HANGER	Mondraker M068
OTHERS	-
WEIGHT	17.2kg

GEOMETRY

MEASUREMENTS / GEOMETRY (Click on image to expand)

	Size	S	M	L	XL
A	Seat Tube Length	380 mm	420 mm	470 mm	510 mm
B	Top Tube Length	605 mm	625 mm	650 mm	670 mm
C	Bottom Bracket Drop	-20 mm	-20 mm	-20 mm	-20 mm
D	Bottom Bracket Height	350 mm	350 mm	350 mm	350 mm
E	Chainstay Length	445 mm	445 mm	445 mm	445 mm
F	Seat Tube Angle, Actual	71°	71°	71°	71°
G	Seat Tube Angle, Effective	76°	76°	76°	76°
H	Head Tube Angle	65°	65°	65°	65°
I	Fork Offset	44 mm	44 mm	44 mm	44 mm
J	Wheelbase	1224 mm	1245 mm	1273 mm	1293 mm
K	Head Tube Length	100 mm	110 mm	130 mm	130 mm
L	Reach	450 mm	470 mm	490 mm	510 mm
M	Stack	621 mm	621 mm	639 mm	639 mm

RESOURCESSIZE GUIDE

DESCRIPTION

Sizes: S: 380mm / M: 420mm / L: 470mm / XL: 510mm
Colors: Gloss Racing Silver / Marlin Blue

SPECS

COMPONENTS / TECHNICAL SPECIFICATIONS

FRAME

SuperFoxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 160mm travel,Forward Geometry, one piece Monoblock upper link, SuperBoost 12x157mm rear axle, tapered headtube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing,Max. capacity sealed bearings, ISCG 05

SIZES

S: 380mm / M: 420mm / L: 470mm / XL: 510mm

REAR SHOCK

Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings

SHOCK SETTINGS

Medium compression, medium rebound, air volume spacer 0.2

FORK

Fox 38 29 Float GRIP RHYTHM, 170mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload

HEADSET

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45°x45°,bottom 51.9x40x8x45°x45°

STEM

Onoff Sulfur FG 30mm 0°, 6061 forged alloy, 31.8mm barbore

HANDLEBAR

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9° backsweep, 5° upsweep,31.8mm barbore

GRIPS

Onoff Twin, 1lock-on, 135mm

SEATPOST

Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L size:425x150mm, XL size: 465x170mm

SADDLE

SDG BEL-AIR 3.0, LPU foam, steel rails

FRONT BRAKE

Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

REAR BRAKE

Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

BRAKE LEVER

Sram DB8, tool-free reach adjust

RIMS

e*thirteen LG1 Enduro, IW30 Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes

SPOKES

e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers

FRONT HUB

e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts

REAR HUB

*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, Shimano freehub

FRONT TIRE

Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead

REAR TIRE

Maxxis Dissector 29x2.4WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead

CRANKSET

Truvativ Descendant 7K Eagle, SuperBoost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm

RINGS

32T, CNC-machined alloy, X-SYNC 2

BOTTOM BRACKET

Sram DUB BSA, sealed bearings, 73mm

PEDALS

CHAIN

Sram SX Eagle, 12s, Powerlock

FRONT DERAILLEUR

REAR DERAILLEUR

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

SHIFT LEVERS

Sram Trigger SX Eagle, 12s, X-Actuation 1:1

CASSETTE

Sram PG-1210, 11-50T, 12s

MOTOR

BATTERY

DISPLAY

DERAILLEUR HANGER

Mondraker M068

OTHERS

WEIGHT

17.2kg

GEOMETRY

MEASUREMENTS / GEOMETRY (Click on image to expand)

Size

Seat Tube Length

380 mm

420 mm

470 mm

510 mm

Top Tube Length

605 mm

625 mm

650 mm

670 mm

Bottom Bracket Drop

-20 mm

Bottom Bracket Height

350 mm

Chainstay Length

445 mm

Seat Tube Angle, Actual

71°

Seat Tube Angle, Effective

76°

Head Tube Angle

65°

Fork Offset

44 mm

Wheelbase

1224 mm

1245 mm

1273 mm

1293 mm

Head Tube Length

100 mm

110 mm

130 mm

Reach

450 mm

470 mm

490 mm

510 mm

Stack

621 mm

639 mm
